Monolithic Dome Thermograph

Monolithic Dome photo taken with a thermographic camera at -25 degrees below zero Fahrenheit. Note the Monolithic Dome is black. This is a heated shop. There is no heat loss through the Dome shell. The door (insulated) is leaking heat especially at the cracks between the sections and along the edges.

Image by Robert Phillips via Canadian Dome Industries

CC BY 4.0
