Thermograph of Dome is Black.

Thermograph of Dome is Black

Figure 2.11: Same building, same situation but further around the building. Note the temperatures on the side bar. The black is about –25°C (–13°F). The colors denote higher temperatures.

Image by Robert Phillips via Monolithic Commons

CC BY 4.0
