Airform Pattern Details at Saddle Transition.

Airform Pattern Details at Saddle Transition

Patterning the transition between a spherical dome and an elliptical dome is partly technical, partly magic. The four interconnected domes are all different shapes and sizes: 30′ × 15′, 40′ × 20′, 50′ × 25′, 40′ × 16′ 8″.

Image by Mike South via Monolithic Commons

CC BY 4.0
