Sketch of the Radial Airform.

Sketch of the Radial Airform

A sketch of how the original Airform membranes are patterned based on a radial gore design. Jack Boyt pioneered this design in the early 1980s. The radial design is best for hemisphere or silo-shaped Monolithic Domes.

Image by Dave South via Monolithic Commons

CC BY 4.0
