Thermograph of Insulated Metal Building.

Thermograph of Insulated Metal Building

Figure 2.16: This thermograph is of a 1980 vintage metal building that is considered well insulated. The picture indicates this is true for a metal building. But even this well-insulated building shows heat loss.

Image by Robert Phillips via Monolithic Commons

CC BY 4.0
