Inflated Airform with Gothic Arch Augments.

Inflated Airform with Gothic Arch Augments

Large areas of the Airform at the tips of the augments will be trimmed off after the structure is solid. This is how the shape of the augments is maintained. The space created provides the crew with room to install the frames as designed.

Image by Mike South via Monolithic Commons

CC BY 4.0

Download image

Original (5280×3956) / Huge (1920×1438) / Large (1600×1198) / Medium (1280×959) / Small (960×719) / Thumb (640×479)

Creating Gothic Arches Using Airform Technology
